Wegner Automotive LSX Whipple 2.9 Drive Kit | Corvette (Y-Body) Offset
WAK040 Whipple 2.9L (8 Rib)
Corvette Offset
The WAK040 LS Front Accessory Drive for the Whipple 2.9L Supercharger is our most popular kit for supercharged LS engines.Ā
Expertly engineered and dyno-tested in house for high-horsepower street use, this pulley kit includes key features such as -
- CAD designed and CNC machined billet aluminum brackets and pulleys for maximum rigidity, eliminating component flex in high performance applications
- Complete belt wrap with an extra idler pulley for NO slip operation
- Internal fan alternator to cool better and allow more RPM
- Dedicated 8 rib supercharger belt
- Multiple blower pulley ratios depending on boost requirements
Please note - this kit was designed utilizing the Corvette belt alignment.Ā Be sure your supercharger is built for the Corvette belt line.
Kit will NOT fit with VVT front covers.
All our accessory drives are built to order - please allow 4-6 weeks for delivery
Note: Only Billet components would come in custom finish. Factory components would come in factory finish.Ā
Our base WAK040 Accessory DriveĀ includes the following -
- ATI Y-body ('Vette) 8 Rib Damper, OE Diameter
- Heavy Duty Belts and Tensioners
- Standard Internal Fan 170 Amp 1 Wire or GM 2 PinĀ Late Model Powermaster Alternator
- GM Type 2 Style Power Steering Pump
- GM LSA / LS3 Style Water Pump
- TCCI AC Compressor
- All necessary Wegner Automotive precision CNC Machined Billet brackets, Pulleys, and Stainless-Steel Mounting Hardware
Finish Color
- Solid Black
- Machined Aluminum
- Two-Tone Diamond Cut ($100)
- Polished Aluminum($300)
Optional Alternator
- 170 Amp Powermaster
- 225 Amp Powermaster ($150)
- 370 Amp Mechman ($300)
Power Steering Reservoir
- Power Steering Reservoir Attached to Pump
- Power Steering -6,-10 A/N fittings for Remote Mount
ATI Damper
- OE Diameter
- 12% Overdrive
Supercharger Pulleys
- Multiple sizes available depending on engine build and desired boost
